How Gear Ratios Work

In shifter karts, gear ratios work similarly to other karts but with an added layer of complexity due to the presence of a multi-speed gearbox. Unlike Touch And Go (TaG) karts with a single gear, shifter karts have a manual transmission, typically with a 6-speed transmission, allowing drivers to change gears during a race. In this article, we look at the basics of gear ratios in shifter karts, and how you can optimize this facet of racing to your advantage.

Primary Gear Ratio

Let us first start with the primary gear ratio. This is the ratio between the engine’s output shaft and the rear axle. It is determined by the number of teeth on the front (drive) sprocket and the rear (driven) sprocket. The front sprocket is connected to the engine, whereas the rear sprocket is connected to the rear axle. For rear sprockets, karters usually use those with around 70-80 teeth, and 10-11 for the fronts.

The first step to finding a gear ratio is checking how many teeth are on the front and rear sprockets. Let’s say the front sprocket has ten teeth, while the rear has 70 (the rear sprockets always have more teeth than the front). Next, to help arrive at a number, drivers typically use this formula:

Examples:

To help visualize this formula, let us use the hypothetical values:

70/10= 7.0

This means that the engine has to rotate seven times to rotate the rear axle once (7:1)

Let’s take another example into the picture:

If you have a 11-tooth front sprocket and a 77-tooth rear sprocket:

77/11 = 7

This means that the engine will rotate the same amount as the above example, but is using a different front & rear sprocket.

Transmission Gear Ratios

An often overlooked area, all Shifter karts have multiple gears, each with their own gear ratio. This determines how much the engine’s RPM is reduced before being transmitted to the wheels. It allows the driver to choose the optimal gear for different parts of the track. After all, if the gear is too low you might experience wheelspin. Too high, and the kart will bog down heavily, having no momentum and speed to drive out of a corner.

When it comes to lower gears (1st, 2nd), these have higher gear ratios, providing more torque and better acceleration. These are useful for starting and exiting corners. Higher Gears (5th, 6th) have lower gear ratios, allowing for higher top speeds on straights. Being in the right gear in certain parts of the track can help shave off those extra tenths.

Different Shapes, Different Sizes

Sprockets come in different shapes and sizes for your racing needs. There are rear sprockets that are either heavy but durable, or light but sensitive, so choose wisely. rear sprockets can have as much as 90 teeth, and others as low as 65. This can affect how a kart handles as the bigger the sprocket, the better it is for acceleration. On the other hand, the smaller the sprocket, the better it is for top speed. Moving onto front sprockets, these can range from 10 teeth, to as high as 13/14 teeth. Be sure to choose the right sprockets to maximize the potential of the kart.

A great way to determine if you are using the right sprockets is by checking your RPM (revolutions per minute). Your engine will have a maximum RPM it can reach, and an optimal minimum RPM for acceleration. If you are reaching the maximum RPM for half the main straight, lower the rear sprocket.

Tuning Gear Ratios:

(Source: TKart)

Now what exactly do these gear ratios entail? A higher primary gear ratio (more teeth on the rear sprocket) provides better acceleration, allowing the kart to be a monster on short circuits with many tight and twisty sections. On the contrary, a lower ratio (fewer teeth on the rear sprocket) allows for higher top speeds. This is good for tracks with long straights.

CONCLUSION

Understanding and mastering gear ratios in shifter karts is essential for competitive racing, as it allows you to tailor your kart’s performance to the specific demands of the track and race conditions. Always be sure to do your due diligence, especially regarding finding your gear ratios. With the help of the formula provided today, can serve as a baseline on how to tune your kart.
